Lab Catalog Supply Code: NED – 18-06-18-0058

Linear unit for Positioning Drive, length of travel: 700mm to 800mm
Minimum Technical Specifications Required  (like or better than):
•    Should involve a toothed belt drive.
•    Tightening mechanism for toothed belt
•    Should prevent damage occurring even if invalid parameters are input for the end limit switches.
•    Should be coupled with a synchronous servo system and the two operated in conjunction.
•    Overall length of travel: 700mm to 800mm
•    Guide rails Should be safely protected from damage due to mechanical impact
Integrated end switches with normally open and normally closed contacts
Linear unit Operation Manual, Lab Instructor Guide and Student Workbook. Linear unit for Educational Vocational, Didactic Technical Training Equipment Labs.
