Axial Flow Pump Test Rig

Lab Catalog Supply Code: MEE-HLM-0014

Axial Flow Pump Test Rig

Pump:-

Axial Flow Pump to Discharge About 150 LPM.

Motor:-

3 HP, Three phase. 400/440 V, AC supply.

Electrical Panel:-

Switch & Energy meter for the measurement of power Input.

Sump Tank:-

M.S. Unit with FRP Lining/S.S Unit of suitable size to store sufficient water for independent circulation through the unit.

Measuring Tank:-

M.S. Unit with FRP Lining/ S.S. Unit of suitable size provided with standard fittings for measuring discharge of water.

Others:-

Piping system consisting of Pipes, Pressure relief valve, Gate valve and fitting with pressure gauge.

Axial Flow Pump Test Rig Operation Manual, Lab Instructor Guide and Student Workbook. Axial Flow Pump Test Rig for Educational Vocational, Didactic Technical Training Equipment Labs.
