Strain Gauge Transducers

Lab Catalog Supply Code: MEE-MEL-0001

Strain Gauge Transducers

Piezo resistive transducer for strain measuremet.

Micrometer 0-20 mm (Accuracy 0.01 mm) for strain generation.

Experiments on Gauge factor determination, Strain indicator, Displacement measurement using Strain gauges.

Strain gauges mounted on cantilever in hal and full Wheatstone bridge and instrumentation amplifier with Zero and spanadjustment for calibration.

Speed Sensing Transducers:-

F to V Converter with span and zero amplifier.

Individual signal conditioning circuit with programmable threshold comparator.

12V DC motor with peed varying from0-4000rpm and rotating lotted wheel having 8 lots.

Sound Sensing Transducers:-

40 KHz gated oscillator to generate Ultrasonic sound waves.

V to I function block to convert voltage O/P into 4 to 20 m A current loop

Sound Sensors:-

Ultrasonic Distance Measuremet.

Dynamic microphone as Sound/ Audio sensor.

Strain Gauge Transducers Operation Manual, Lab Instructor Guide and Student Workbook. Strain Gauge Transducers for Educational Vocational, Didactic Technical Training Equipment Labs.
