Lab Catalog Code: ELECTRICLABTransfer Lab002399
Extended Surface Heat Exchanger
Extended Surface Heat Exchanger Operation Manual, Lab Instructor Guide and Student Workbook included. Designed for Educational Vocational, Didactic Technical Training Equipment Labs.
- ISO Certified Manufacturing
- Bulk Tender Supply Available
- Complete Documentation Included
- Worldwide Shipping & Installation
Extended Surface Heat Exchanger
Extended Surface Heat Exchanger
The
rod is manufactured from a solid cylindrical brass bar with a constant
diameter of 10mm. The rod is mounted horizontally with support at both
ends and positioned to avoid the influence of adjacent surfaces. The rod
is heated by a cartridge type electric heating element which operates
at low voltage for increased operator safety and is protected by a
thermostat to prevent damage from overheating. The heating element is
inserted co-axially into the end of the rod and is rated to produce 20
Watts nominally at 24V DC into the rod. The power supplied to the heated
rod can be varied and measured. Eight thermocouples are attached to the
surface of rod at equal intervals of 50mm giving an overall
instrumented length of 350mm. Each thermocouple is wrapped around the
rod to minimize errors by conduction. One thermocouple is mounted
adjacent to the heated rod to measure the ambient air temperature. All
temperatures are measured using K-type thermocouples, each fitted with a
miniature plug for direct connection to the service unit. The rod is
coated with a heat resistant matt black paint which provides a
consistent emissivity close to unity The heated end of the rod is
mounted co-axially inside a plastic housing which provides an air gap
and insulates the area occupied by the heater to minimize heat loss and
prevent burns to the operator
- A
small-scale accessory designed to demonstrate the temperature profile
and heat transfer characteristics for an extended surface when heat
flows along the rod by conduction and heat is lost along the rod by
combined convection and radiation - The extended surface comprises
a 10mm diameter, long brass rod mounted horizontally and heated at one
end with a 20 Watt, 24V DC heater. - Eight thermocouples mounted at 50mm intervals along the rod provide the temperature distribution.
- Temperature of the ambient air is measured by an independent thermocouple.
- The
accessory is mounted on a PVC baseplate which is designed to stand on
the bench top and connect to the Heat Transfer Service Unit without the
need for tools. - A comprehensive instruction manual is supplied.
Technical Details of Extended Surface Heat Exchanger
The
rod is manufactured from a solid cylindrical brass bar with a constant
diameter of 10mm. The rod is mounted horizontally with support at both
ends and positioned to avoid the influence of adjacent surfaces. The rod
is heated by a cartridge type electric heating element which operates
at low voltage for increased operator safety and is protected by a
thermostat to prevent damage from overheating. The heating element is
inserted co-axially into the end of the rod and is rated to produce 20
Watts nominally at 24V DC into the rod. The power supplied to the heated
rod can be varied and measured. Eight thermocouples are attached to the
surface of rod at equal intervals of 50mm giving an overall
instrumented length of 350mm. Each thermocouple is wrapped around the
rod to minimize errors by conduction. One thermocouple is mounted
adjacent to the heated rod to measure the ambient air temperature. All
temperatures are measured using K-type thermocouples, each fitted with a
miniature plug for direct connection to the service unit. The rod is
coated with a heat resistant matt black paint which provides a
consistent emissivity close to unity The heated end of the rod is
mounted co-axially inside a plastic housing which provides an air gap
and insulates the area occupied by the heater to minimize heat loss and
prevent burns to the operator
Shipping & Installation
We dispatch Extended Surface Heat Exchanger from our Ambala Cantt manufacturing facility to destinations across 90+ countries. All shipments include comprehensive documentation, technical manuals, and a Lab Instructor Guide.
- Packaging: Export-grade wooden crate with anti-corrosion lining
- Lead Time: 4-6 weeks for standard orders, customised lead time for bulk tenders
- Installation: On-site installation and commissioning by our certified engineers (optional)
- Training: Hands-on training for instructors and lab technicians provided
- Warranty: 12-month manufacturer warranty against material and workmanship defects
