This Laboratory scale working model housed on a M.S. Square tube frame
and further mounted on a wheels(CI) with instrumentation panel is used:-
i) To study the vapor compression refrigeration cycle.
ii) To calculate Co-efficient of performance (C.O.P.).
Features:-
Capacity : 1/83 HP
Range : 0 to 300 psi /- 30 “ Hg to 150 psi
Digital Temperature Indicator : 30 to 199.9 deg.c.
Optional : At Extra Cost Line Voltage Corrector
Capacity : 2KVA
Output : 230 V+/- 10%
Cold Storage Test Rig Operation Manual, Lab Instructor Guide and Student Workbook. Cold Storage Test Rig for Educational Vocational, Didactic Technical Training Equipment Labs.
